MP-702 6C33C OTL Mono Blocks Power Amplifier
Product Code: MP-702
Availability: Out Of Stock
Availability: Out Of Stock
Price: $2,750.00 USD
*Sold in Pair. Price is for one pair (two units). 220V-240V Input Voltage Only.
Our Flagship Mono Blocks!
Each MP-702 employs four 6C33C power tubes to provide 100W high output power. Since 6C33C is low impedance power tubes, we use OTL circuit design to eliminate output transformers distortion and limited frequency responses, therefore MP-702 sounds very natural, clean and transparent. It also quite powerful and dynamic. It can be driven by Musical Paradise MP-D2 DAC Pre-Out and MP-701 Preamplifier. It can also work with your existing preamplifiers.
|
Circuit |
Class AB OTL Push Pull |
|
Output |
100W |
|
Input Impedance |
250K |
|
Output Impedance |
4-16ohm Speakers |
|
Frequency Response |
10 Hz to 40KHz |
|
THD |
<1% |
|
Tubes |
4 x 6C33C, 2 x 6J8P (or 6SJ7 Optional), 1x 12AX7 |
|
Power Transformer(s) |
400W Toroidal + 550W Toroidal (Total 950W) |
|
Resistors |
1% Dale Military Metal Film and Wound Wire |
|
Coupling Capacitors |
2x High End Black Wima 1.5uF |
|
Filtering Capacitors |
All Philips |
|
AC Power Requirements |
220-240 VAC @ 50/60 Hz |
|
Power Consumption |
450W Idle |
|
Break-In Time |
100 hours of music playing time |
|
Finish |
Silver chassis with silver aluminum faceplate |
|
Weight |
30KG Each |
|
Dimensions |
20CM H x 52CM W x 52CM D |
